150W UL & FCC Certified Super Thin LED Power Supply – 24V/6.25A, 36V, or 48V Constant Voltage Driver

Name: 150W UL amp FCC Certified Super Thin LED Power Supply 24V625A 36V or 48V Constant Voltage Driver
Brand: ANENpower
Price: 1 USD

Brand Name : ANENpower

Model Number : APL150S

Certification : UL/CUL, FCC, CE, GS, TUV, CB, RCM, SAA, PSE, KC, UKCA

Place of Origin : Shenzhen

MOQ : 500pcs

Price : Please contact our Sales

Payment Terms : 50% deposit, 50% before dispatch

Supply Ability : 500,000.00pcs/month

Delivery Time : 18~25 working days after receiving the deposit

Packaging Details : PE bag / White box / Custom made

Power : 150W max.

Input : 90-265V AC

Output Voltage : 12V/ 24V/ 36V /48V

Output Current : 12.5A/ 6.25A/ 4.166A/ 3.125A

Dimension(LxWxH) : 179x58x20mm

Voltage Tolerance : ±5%

Riple(P-P) : ＜1%

Efficiency : ≥90%

Applicant : Cabinet lights, LED strips, LED indoor lighting, LED decorative lighting, LED building lighting

Contact Now

150W UL & FCC Certified Super Thin LED Power Supply – 24V/6.25A, 36V, or 48V Constant Voltage Driver

Engineered for heavy-duty LED applications, this 150W ultra-slim switching power supply delivers reliable, high-efficiency performance with 24V at 6.25A, plus selectable 36V or 48V outputs—ideal for high-power LED strips, commercial signage, and architectural lighting. Certified to UL and FCC safety and EMI standards, it ensures safe, compliant operation in North American and international installations. Its super thin, compact design fits neatly into confined spaces without sacrificing power. Built for stability, longevity, and silent operation, this driver is the smart choice for demanding indoor LED projects that require robust, certified performance.

- Universal Input: 90-265V AC 50/60Hz
- RoHS Compliance
- EMI Standard EN55015
- Safety Standard: EN61347-1, EN61347-2-13, UL8750
- Inrush current<65A AC230V/50Hz - High efficiency & low power consumption
- Short Circuit, Over Current and Over Voltage Protection
- Over temperature protection
- 100% full load burn-in test
- Auto restart after remove of fault conditions
- IP20 protection rating

MODEL DETAIL SPEC.		APL150S -12012500	APL150S -2406250	APL150S -3604166	APL150S -4803125
INPUT	Input Voltage:	100-240VAC/200-240VAC
	Input Frequency:	50/60Hz
	Inrush Current:	65A/230VAC at full load
	AC Current:	0.087A/115VAC 0.043A/230VAC
	Leakage Current:	＜0.25mA/240VAC
	Efficiency:	88%
OUTPUT	DC Voltage:	12V	24V	36V	48V
	Rated Current:	12.5A	6.25A	4.166A	3.125A
	Rated Power:	150W
	Voltage Tolerance:	±5.0%
	Ripple and Noise:	120mVp-p	240mVp-p	360mVp-p	480mVp-p
	Line Regulation:	±3%
	Load Regulation:	±5%
	Setup, Rise, Hold Up time:	1s, 10ms/60ms 230VAC 1000ms, 1ms/25ms 115VAC at full load
ENVIRONMENTAL	Operating Temperature:	-20 ~ +50℃ (Refer to "Derating Curve")
	Storage Temp:	-40℃ ~ 85℃
	Storage Humidity:	20 ~ 95% RH
	Working Humidity:	20 ~ 95% RH non-condensing
PROTECTION	Over Load:	Above 105%-130% rated output power
		Protection type: Hiccup mode, recovers automatically after fault condition is removed
	Over Voltage:	12V:13.8 ~ 16.2V 24V : 27.6 ~ 32.4V 36V:41.4 ~ 48.6V 48V:55.2~64.8V
		Protection type: Shut down o/p voltage, re-power on to recover
	Over Temperature:	Shut down o/p voltage, re-power on to recover
SAFETY & EMC	Safety Regulations:	EN61347-2-13:2014+A1:2017,EN61347-1:2015;EN62493:2015
	Withstand Voltage:	I/P-O/P:3.75KVAC
	Harmonic	EN61000-3-2 Class C EN61000-3-3
	EMI:	Compliance to EN55015
	EMS:	compliance to 61547:2009
OTHER	MTBF:	200,000 Hours Minimum at Full Load at 25℃ Ambient
	Size:	1795820mm
	Weight:	150g / pcs
	Packaging:	50PCS/CTN
